Mechanized Polyurethane Purification Panel
-MOQ：50 Square Meters【Required】
-Core Material： High-density polyurethane foam elastomer
-Surface Material： Galvanized steel plate, color-coated steel plate, 304 stainless steel plate (optional)
-Core Density： 35-45kg/m³
-Standard Thickness：50mm/75mm/100mm (customizable)
- Overview
- Specifications
- Product Features
- Application Scenarios
- FAQ
- Recommended Products
Welcome to our premium Mechanized Polyurethane Purification Panel solutions, where ultimate thermal insulation energy saving and professional fireproof enclosure functions are perfectly integrated. Our Mechanized Polyurethane Purification Panel takes high-density polyurethane foam as the core material, matched with high-quality galvanized steel plates, color-coated steel plates or 304 stainless steel plates as the surface layer, and is made by high-temperature and pressure compounding and precision edge trimming and grooving through a high-speed automatic forming machine.
It is a high-performance elastomer sandwich panel between plastic and rubber. The product integrates A1 grade fire resistance, ultra-low thermal conductivity, light weight and high strength, sealing and waterproofing and other characteristics, creating a constant temperature, energy-saving, safe and durable enclosure structure for cleanrooms. Whether you are a cleanroom engineering designer, contractor or factory builder, it is the optimal solution for building constant temperature clean spaces.
| Item | Specification |
|---|---|
| MOQ | 50 Square Meters【Required】 |
| Core Material | High-density polyurethane foam elastomer |
| Surface Material | Galvanized steel plate, color-coated steel plate, 304 stainless steel plate (optional) |
| Core Density | 35-45kg/m³ |
| Standard Thickness | 50mm/75mm/100mm (customizable) |
| Standard Width | 950mm/1150mm (non-standard customizable) |
| Length | Customized according to customer project requirements |
| Fire Resistance Grade | A1 (non-combustible) |
| Thermal Conductivity | ≤0.024 W/(m·K) |
| Compressive Strength | ≥0.3MPa |
| Water Absorption | ≤3% (waterproof and non-absorbent) |
| Splicing Method | Tongue-and-groove splicing |
| Sealing Process | Galvanized steel strip edge sealing + high-strength flame-retardant structural adhesive bonding |
| Compliance | ISO9001 Quality Management System, ISO14001 Environmental Management System, A1 fire resistance test certification, thermal insulation performance test report |
Ultimate Thermal Insulation: Polyurethane core material is the clean panel core material with the best thermal insulation performance. The ultra-low thermal conductivity can effectively block the heat transfer between indoor and outdoor, greatly reduce the air conditioning and heating energy consumption of the cleanroom, and realize constant temperature and energy-saving operation.
A1 Grade Fire Resistance & Flame Retardant: Adopting flame-retardant polyurethane formula, reaching A1 grade non-combustible fire resistance grade, no toxic smoke release and no melting dripping when exposed to fire, effectively blocking the spread of flame, meeting the strict fire protection requirements of cold chain, electronics and other industries.
Light Weight & High Strength: The core material is light in weight, greatly reducing the bearing load of the building main body, and has excellent compressive and anti-deformation performance. The surface layer and core material are firmly bonded without delamination, making transportation and installation more convenient.
Excellent Waterproof & Sealing: The polyurethane core material itself has hydrophobic characteristics. With a strict edge sealing and sealing process, the whole panel is waterproof and non-absorbent, effectively preventing water vapor from invading and avoiding core material failure due to moisture.
Clean & Easy to Maintain: The surface of the steel plate is smooth and flat, no dust generation and accumulation, scratch and corrosion resistant, can be directly wiped and cleaned with disinfectant, no fiber shedding, in line with the cleanroom hygiene standards.
Flexible Customization: Support non-standard customization of thickness, width and length. The surface layer can be matched with anti-static and antibacterial coatings to adapt to the personalized engineering needs of different cleanliness levels and different constant temperature requirements.
Durable in Use: The core material is anti-aging and non-degradable. The strict edge sealing process prevents dust and water vapor from invading. The service life is more than 15 years under normal use, and the later maintenance cost is low.
Cold Chain Food Industry: Suitable for cold chain food processing workshops, low-temperature refrigeration clean areas, food quick-freezing workshops. The ultimate thermal insulation performance effectively maintains the indoor low temperature and reduces refrigeration energy consumption.
Electronics Industry: Adapting to constant temperature and humidity electronic component clean workshops and semiconductor manufacturing plants, accurately controlling the indoor temperature and avoiding temperature fluctuations affecting precision instruments and chip production.
Pharmaceutical Industry: Used in low-temperature pharmaceutical workshops and medical cold chain storage clean areas, taking into account constant temperature requirements and fire safety, in line with the pharmaceutical GMP production specifications.
HVAC Clean Engineering: Suitable for ceilings and partition walls of various cleanrooms that require constant temperature control, creating an energy-saving and efficient clean enclosure system.
Industrial Constant Temperature Factories: Adapting to industrial clean factories with strict environmental temperature requirements such as precision instrument manufacturing and new energy material research and development.
Q: What is the lead time for a custom Mechanized Polyurethane Purification Panel order?
A: The lead time typically ranges from 7 to 15 working days, depending on the customization complexity and order size of the product.
Q: What is the advantage of the thermal insulation performance of the mechanized polyurethane purification panel compared with the rock wool panel?
A: The thermal conductivity of polyurethane core material is much lower than that of rock wool, and its thermal insulation performance is 2-3 times that of rock wool panel. It can achieve better constant temperature effect under the same thickness and greatly reduce the later energy consumption cost.
Q: Can the panel be installed in the outdoor clean auxiliary area?
A: Yes, the panel has excellent waterproof and anti-aging performance. With outdoor special surface coating, it can be adapted to the enclosure engineering of outdoor clean auxiliary areas, with both thermal insulation and fire protection.
Q: How do I maintain and clean the Mechanized Polyurethane Purification Panel?
A: The panel is easy to maintain and clean. Regular cleaning with a soft cloth with mild detergent or water will keep the surface clean. Avoid using strong acid and strong alkali cleaners to prevent damage to the surface steel plate.
Q: Will the polyurethane core material shrink or deform?
A: No, the high-density polyurethane core material we use is shaped by high temperature and high pressure, with excellent anti-shrinkage and anti-deformation performance, and there will be no core material collapse and panel deformation during long-term use.
Q: Do you provide installation accessories and technical guidance for this panel?
A: While we mainly supply purification panel products, we can provide one-stop supporting installation accessories such as purified aluminum profiles, special flame-retardant sealants and splicing buckles. At the same time, we can provide professional installation technical guidance or recommend certified installation teams.
