Mechanized Magnesium Oxysulfate Purification Panel
-MOQ：50 Square Meters【Required】
-Core Material：High-density environmental protection magnesium oxysulfate cementitious material
-Surface Material：Galvanized steel plate, color-coated steel plate, 304/316 stainless steel plate (optional)
-Core Density：200-220kg/m³
-Standard Thickness：50mm/75mm/100mm (customizable)
- Overview
- Specifications
- Product Features
- Application Scenarios
- FAQ
- Recommended Products
Welcome to our premium Mechanized Magnesium Oxysulfate Purification Panel solutions, where professional cleanroom enclosure systems are perfectly integrated with ultimate moisture and fire resistance functionality. Our Mechanized Magnesium Oxysulfate Purification Panel is an upgraded version of traditional magnesium-based purification panels. It is made of high-density magnesium oxysulfate cementitious material with magnesium sulfate and magnesium oxide as core environmental raw materials, matched with high-quality galvanized steel plates, color-coated steel plates or stainless steel plates as surface layers, and formed by high-temperature and pressure compounding, edge trimming and grooving through a high-speed automatic forming machine.
The product combines A1 grade non-combustible fire resistance, super moisture resistance, anti-halogen reversion and high structural stability, building a durable, safe and clean enclosure structure for high-humidity clean scenarios. Whether you are a cleanroom engineering designer, contractor or factory builder, it is the optimal solution for creating clean spaces in high-humidity environments.
| Item | Specification |
|---|---|
| MOQ | 50 Square Meters【Required】 |
| Core Material | High-density environmental protection magnesium oxysulfate cementitious material |
| Surface Material | Galvanized steel plate, color-coated steel plate, 304/316 stainless steel plate (optional) |
| Core Density | 200-220kg/m³ |
| Standard Thickness | 50mm/75mm/100mm (customizable) |
| Standard Width | 950mm/1150mm (non-standard customizable) |
| Length | Customized according to customer project requirements |
| Fire Resistance Grade | A1 (non-combustible) |
| Fire Resistance Duration | ≥1h |
| Moisture Resistance | Water absorption ≤8% |
| Anti-Halogen Reversion | No halogen return and no efflorescence during long-term use in high-humidity environments |
| Thermal Conductivity | ≤0.038 W/(m·K) |
| Compressive Strength | ≥3.0MPa |
| Splicing Method | Tongue-and-groove splicing |
| Sealing Process | Galvanized steel strip edge sealing + high-strength environmental protection structural adhesive bonding |
| Compliance | ISO9001 Quality Management System, ISO14001 Environmental Management System, A1 fire resistance test certification, moisture resistance performance test report |
Ultimate Fire Resistance: With the highest A1 grade non-combustible fire resistance, it does not burn when exposed to fire, releases no toxic smoke and has no melting and dripping, effectively blocking the spread of flame and meeting the strict fire code requirements of pharmaceutical, food, electronics and other industries.
Super Moisture & Anti-Halogen Reversion: The modified magnesium oxysulfate formula abandons chloride ions and is combined with a dense forming process, fundamentally inhibiting water penetration and salt efflorescence. The performance remains stable for long-term use in humid southern regions and high-humidity processing workshops.
High Structural Strength: The core material is pressed at high density with excellent compressive and flexural performance, not easy to deform or damage. The surface layer and core material are firmly bonded without delamination, suitable for various installation scenarios such as cleanroom ceilings and partition walls.
Green Environmental Protection: The core material contains no formaldehyde or asbestos, with no pollution in the production process and no harmful gas release after installation. It meets the national environmental protection building material standards and creates a healthy and pollution-free clean production environment.
Clean & Easy to Maintain: The surface of the steel plate is smooth and flat, no dust generation and accumulation, water-resistant, corrosion-resistant and easy to wipe. It can be directly cleaned with disinfectant without fiber shedding, meeting the ultra-high hygienic requirements of food and pharmaceutical industries.
Flexible Customization: Support non-standard customization of thickness, width and length. The surface layer can be matched with anti-static and antibacterial coatings to adapt to the personalized needs of different cleanliness levels and different high-humidity scenarios.
Durable in Use: The edge sealing process is tight, effectively preventing the intrusion of water vapor and dust. The core material is anti-aging and non-degradable, with a service life of more than 15 years under normal use, which greatly reduces the later maintenance and replacement costs.
Food Processing Industry: Suitable for baking workshops, beverage filling areas, dairy processing plants, aquatic product processing workshops, maintaining dry and clean in high-humidity environments, preventing mold growth and complying with food hygiene production standards.
Pharmaceutical Industry: Adapting to GMP sterile preparation workshops, traditional Chinese medicine piece production areas, biopharmaceutical laboratories, taking into account fire resistance, moisture resistance and high cleanliness requirements, and building a safe and compliant pharmaceutical enclosure space.
Cosmetic Industry: Used in cosmetic sterile production workshops, batching rooms and packaging areas to avoid product contamination by halogen return and maintain the cleanliness and dryness of the production environment.
Electronics Industry: Suitable for electronic component clean workshops in humid southern regions, preventing environmental moisture from invading and affecting precision instruments, with both fire and moisture protection.
Coastal/Humid Area Construction: Adapting to clean factories in coastal humid cities, cold chain food processing workshops and other enclosure projects with dual requirements for moisture and fire resistance.
Q: What is the lead time for a custom Mechanized Magnesium Oxysulfate Purification Panel order?
A: The lead time typically ranges from 7 to 15 working days, depending on the customization complexity and order size of the product.
Q: Can the Mechanized Magnesium Oxysulfate Purification Panel be installed in a long-term high-humidity environment?
A: Yes, this product is specially designed for high-humidity environments, with water absorption far lower than industry standards and excellent anti-halogen reversion performance, no efflorescence or deformation during long-term use in high-humidity environments.
Q: What is the core difference between this panel and the traditional glass magnesium panel?
A: The core difference lies in the moisture resistance and anti-halogen reversion performance. Traditional glass magnesium panels are prone to halogen return and efflorescence due to chloride ion precipitation, while magnesium oxysulfate panels abandon chloride ions in the formula to completely solve this pain point, with better structural strength and moisture resistance.
Q: How do I maintain and clean the Mechanized Magnesium Oxysulfate Purification Panel?
A: The panel is easy to maintain and clean. Regular cleaning with a soft cloth with mild detergent or water will keep the surface clean. Avoid using strong acid, strong alkali or abrasive cleaners to prevent damage to the surface steel plate.
Q: Can stainless steel plate be selected for the surface layer? What are the advantages?
A: Absolutely! 304/316 stainless steel plate can be selected as the surface layer, which has better corrosion and oxidation resistance, more suitable for scenarios with ultra-high hygienic requirements in food and pharmaceutical industries, and the surface is easier to clean with a longer service life.
Q: Do you provide installation accessories and technical guidance for this panel?
A: While we mainly supply purification panel products, we can provide one-stop supporting installation accessories such as purified aluminum profiles, special sealants and splicing buckles. At the same time, we can provide professional installation technical guidance or recommend certified installation teams.
