Mechanized Hollow Glass Magnesium Purification Panel
-MOQ：50 Square Meters【Required】
-Core Material：Environmentally friendly hollow glass magnesium cementitious material (hollow structure)
-Surface Material：Galvanized steel plate, color-coated steel plate, 304 stainless steel plate (optional)
-Core Density：120-150kg/m³
-Standard Thickness：50mm/75mm/100mm (customizable)
- Overview
- Specifications
- Product Features
- Application Scenarios
- FAQ
- Recommended Products
Welcome to our premium Mechanized Hollow Glass Magnesium Purification Panel solutions, where professional lightweight enclosure is perfectly integrated with efficient fire, moisture and mildew resistance functions. Our Mechanized Hollow Glass Magnesium Purification Panel is made of environmentally friendly glass magnesium raw material with hollow structure core, matched with high-quality galvanized steel plates, color-coated steel plates or 304 stainless steel plates as the surface layer, and formed by high-temperature and pressure compounding and precision edge trimming and grooving through a high-speed automatic forming machine.
The unique hollow structure design effectively reduces the overall weight of the panel while maintaining excellent structural strength. The core material itself is moisture-proof, mildew-proof and non-moisture-absorbing, and the surface layer is firmly bonded with the core material, endowing the product with the core characteristics of Class A fire resistance, light weight, energy saving and stable durability. It creates a safe, lightweight and easy-to-install enclosure structure for cleanrooms. Whether you are a cleanroom engineering designer, contractor or factory builder, it is a cost-effective optimal solution for building clean spaces with high requirements.
| MOQ | 50 Square Meters【Required】 |
| Core Material | Environmentally friendly hollow glass magnesium cementitious material (hollow structure) |
| Surface Material | Galvanized steel plate, color-coated steel plate, 304 stainless steel plate (optional) |
| Core Density | 120-150kg/m³ |
| Standard Thickness | 50mm/75mm/100mm (customizable) |
| Standard Width | 950mm/1150mm (non-standard customizable) |
| Length | Customized according to customer project requirements |
| Fire Resistance Grade | Class A (non-combustible) |
| Fire Resistance Duration | ≥1h |
| Moisture Resistance | Water absorption ≤5%, moisture and mildew proof |
| Thermal Conductivity | ≤0.035 W/(m·K) |
| Compressive Strength | ≥2.5MPa |
| Splicing Method | Tongue-and-groove splicing |
| Sealing Process | Galvanized steel strip edge sealing + high-strength environmental protection structural adhesive bonding |
| Compliance | ISO9001 Quality Management System, ISO14001 Environmental Management System, Class A fire resistance test certification, moisture resistance performance test report |
Class A Ultimate Fire Resistance: The hollow glass magnesium core material is made of natural inorganic raw materials, which is a Class A non-combustible material. It does not burn when exposed to fire, releases no toxic smoke and has no melting dripping, effectively blocking the spread of flame and meeting the strict fire code requirements of pharmaceutical, electronic, food and other industries. It is an ideal choice for high fire protection scenarios.
Lightweight & High Structural Strength: The unique hollow structure design greatly reduces the self-weight of the panel, reducing the load-bearing capacity of the building main body. Meanwhile, the core material has high density and excellent compressive and flexural properties. The surface layer and core material are firmly bonded without delamination, suitable for various non-load-bearing installation scenarios such as cleanroom ceilings and partition walls, making transportation and installation more convenient.
Excellent Moisture & Mildew Resistance: The glass magnesium core material itself contains no chloride ions, matched with the tight hollow sealing structure, with extremely low water absorption. It will not absorb moisture, return halogen or produce efflorescence even in long-term high-humidity environments, effectively preventing mold growth. It is suitable for high-humidity clean scenarios such as southern humid areas and food processing workshops with stable and durable performance.
High-Quality Thermal Insulation & Energy Saving: The hollow glass magnesium core material with low thermal conductivity can effectively block the heat transfer between indoor and outdoor, reduce the air conditioning energy consumption of the cleanroom, realize constant temperature and energy-saving operation. Compared with traditional solid panels, it has better thermal insulation effect and reduces later operation costs.
Clean & Easy to Maintain: The surface of the steel plate is smooth and flat, no dust generation and accumulation, corrosion and scratch resistant. It can be directly wiped and cleaned with disinfectant without fiber shedding, meeting the clean hygiene standards of food, pharmaceutical and electronic industries. Daily maintenance is simple and convenient.
Green & Healthy: The core material is made of environmentally friendly raw materials without formaldehyde, asbestos and harmful volatile substances, with no pollution in the production process and no peculiar smell release after installation. It meets the national environmental protection building material standards and creates a healthy and pollution-free clean production environment.
Standardized & Easy to Install: The standardized specification design, small tongue-and-groove splicing gap and good airtightness, ordinary steel structure construction teams can install it, greatly shortening the construction period and adapting to the construction of large-scale clean engineering projects, while reducing installation costs.
Pharmaceutical Industry: Suitable for GMP pharmaceutical workshops, sterile preparation rooms, biological laboratories, hospital clean corridors, meeting fire safety and lightweight installation requirements, and building a safe and compliant pharmaceutical enclosure space.
Electronics Industry: Adapting to electronic component clean workshops and semiconductor manufacturing plants, lightweight panels reduce the load-bearing capacity of ceilings, while providing fire protection, dustproof and soundproof functions to ensure the stable operation of precision instruments.
Food Industry: Used in food processing workshops, beverage production clean areas and dairy processing plants, excellent moisture and mildew resistance prevents mold growth, in line with food hygiene production standards, suitable for high-humidity environments.
Industrial Clean Factories: Suitable for partition walls, ceilings and non-load-bearing enclosure structures of various industrial clean factories, adapting to industrial production environments with high fire protection and energy-saving requirements.
Research Institutions: Used in scientific research laboratories and new energy material research and development cleanrooms, creating a lightweight, safe and energy-saving experimental space to meet the dual requirements of environment and load-bearing in the laboratory.
Humid Area Construction: Especially suitable for clean factories in rainy southern regions and coastal humid cities, completely solving the industry pain points of traditional panels such as moisture deformation and halogen return.
Q1: What is the lead time for a custom Mechanized Hollow Glass Magnesium Purification Panel order?
A: The lead time typically ranges from 7 to 15 working days, depending on the customization complexity and order size of the product. Conventional specifications can be delivered quickly.
Q2: What is the load-bearing capacity of the Mechanized Hollow Glass Magnesium Purification Panel, and can it be used for large-area ceilings?
A: The panel has excellent compressive and flexural properties, with high core material density and stable structure. It can be used for conventional cleanroom ceilings and partition walls. For large-area ceilings, standard keel arrangement is required. Our company can provide installation technical guidance to ensure construction safety.
Q3: Will this panel produce halogen return or efflorescence in high-humidity environments?
A: No. The hollow glass magnesium core material contains no chloride ions, matched with the tight edge sealing process, with extremely low water absorption. It will not produce halogen return or efflorescence during long-term use in high-humidity environments with stable performance.
Q4: How do I maintain and clean the Mechanized Hollow Glass Magnesium Purification Panel?
A: The panel is easy to maintain and clean. Regular cleaning with a soft cloth with mild detergent or water will keep the surface clean. Avoid using strong acid, strong alkali or abrasive cleaners to prevent damage to the surface steel plate.
Q5: What is the core difference between the Mechanized Hollow Glass Magnesium Purification Panel and the solid glass magnesium purification panel?
A: The core difference lies in structure and weight. The hollow type is a lightweight design, with self-weight about 30% lighter than the solid type, reducing building load-bearing and with better thermal insulation performance; the solid type has a more compact structure with slightly higher compressive strength, suitable for small-area load-bearing scenarios. They can be flexibly selected according to project requirements.
Q6: Do you provide installation accessories and technical guidance for this panel?
A: While we mainly supply purification panel products, we can provide one-stop supporting installation accessories such as purified aluminum profiles, special sealants and splicing buckles. At the same time, we can provide professional installation technical guidance or recommend certified installation teams to ensure smooth construction.
